Superwinch LT4000SR 12V Synthetic Rope Winch

Built for action, the Superwinch LT4000SR Winch provides up to 4,000 lbs of reliable pulling power. The LT4000SR is a great choice for a quality, well-built winch that delivers a powerful performance, season after season. The Superwinch LT Series features tried-and-true designs perfected over the years to offer unmatched durability and performance.

Features

• 12V DC 4,000 lbs rated line pull

• Sealed 1.4 HP permanent magnet motor

• 3-Stage planetary gearing with 166:1 ratio

• Sealed solenoid, circuit breaker protected

• Free-spooling, ergonomic control clutch

• 3/16 in x 50 ft synthetic rope

• Heavy-duty, clevis pinned, latched hook

 •Aluminum hawse fairlead

• 12 ft hand-held remote with handlebar mounted rocker switch



Specifications
Brake: Automatic, 100% Load Holding
Clutch: Free-Spooling, Ergonomic Control
Dimensions: N/A
Drum Diameter: 2.0in (50.2mm)
Drum Length: 2.9in (74mm)
Fairlead: Aluminum Machined Hawse
Gear Ratio: 166:1
Gearing: 3-Stage Planetary
Hook: Heavy-Duty, Clevis Pinned Latched
Installed Weight: 25 lbs (11.34 kg)
Line Pull, 0 lbs: 20 Amps Motor Draw/18 FPM (5.4 MPM) Line Speed
Line Pull, 4,000 lbs: 210 Amps Motor Draw/4.5 FPM (1.3MPM) Line Speed
Motor: Sealed 1.4 HP
Mounting Bolt Pattern: 3.0in x 4.87in (76mm x 124mm)
Rated Line Pull: 4,000 lbs (1814.3 kg)
Remote: Handheld with 12ft cord plus Handle Bar Rocker Switch
Rope: Synthetic 3/16in x 50ft (4.8mm x 15.0m)
Solenoid: Sealed Solenoid, Circuit Breaker Protected
Warranty: 1 Year Limited
